[APM] Alert counts in Service groups#144484
Merged
MiriamAparicio merged 30 commits intoelastic:mainfrom Dec 12, 2022
Merged
Conversation
ogupte
added
release_note:skip
ogupte
force-pushed
the
apm-143613-service-groups-alert-count
branch
from
118eac2 to
cc6719e
Compare
Contributor
|
Pinging @elastic/apm-ui (Team:APM) |
yngrdyn
reviewed
Nov 4, 2022
yngrdyn
reviewed
Nov 4, 2022
x-pack/plugins/apm/public/components/app/service_groups/service_group_save/create_button.tsx
Outdated
Show resolved
Hide resolved
dgieselaar
reviewed
Nov 4, 2022
Contributor
dgieselaar
left a comment
dgieselaar
left a comment
There was a problem hiding this comment.
@ogupte can you add API tests?
ymao1
reviewed
Nov 4, 2022
Contributor
There was a problem hiding this comment.
Is it really needed? Can we just render the translation if serviceCountis defined?
Contributor
Author
There was a problem hiding this comment.
This was in place for 8.5 in order to avoid a jump in height after service counts were loaded. But we may want to re-think the loading state for these cards of service groups.
...plugins/apm/public/components/app/service_groups/service_groups_list/service_groups_list.tsx
Outdated
Show resolved
Hide resolved
x-pack/plugins/apm/server/routes/service_groups/get_services_counts.ts
Outdated
Show resolved
Hide resolved
ymao1
reviewed
Nov 4, 2022
ymao1
reviewed
Nov 4, 2022
dgieselaar
reviewed
Nov 5, 2022
x-pack/plugins/apm/server/routes/service_groups/get_service_group_alerts.ts
Outdated
Show resolved
Hide resolved
dgieselaar
reviewed
Nov 5, 2022
x-pack/plugins/apm/server/routes/service_groups/get_service_group_alerts.ts
Outdated
Show resolved
Hide resolved
sorenlouv
reviewed
Nov 10, 2022
x-pack/plugins/apm/server/routes/service_groups/get_apm_alerts_client.ts
Outdated
Show resolved
Hide resolved
sorenlouv
reviewed
Nov 10, 2022
x-pack/plugins/apm/server/routes/service_groups/get_apm_alerts_client.ts
Outdated
Show resolved
Hide resolved
sorenlouv
reviewed
Nov 10, 2022
x-pack/plugins/apm/server/routes/service_groups/get_service_group_alerts.ts
Outdated
Show resolved
Hide resolved
fkanout
approved these changes
Nov 10, 2022
Contributor
fkanout
left a comment
fkanout
left a comment
There was a problem hiding this comment.
Actionable Observability changes LGTM
ymao1
reviewed
Nov 10, 2022
x-pack/plugins/apm/server/routes/service_groups/get_service_group_alerts.ts
Outdated
Show resolved
Hide resolved
…p-level mapping - adds click thru for alerts count badge to observability alerts paged filtered by service group kuery
sorenlouv
reviewed
Dec 1, 2022
| const start = Date.now() - 24 * 60 * 60 * 1000; | ||
| const end = Date.now(); | ||
|
|
||
| async function callApi() { |
Member
There was a problem hiding this comment.
Suggested change
| async function callApi() { | |
| async function getServiceGroupCounts() { |
sorenlouv
reviewed
Dec 1, 2022
| type: string; | ||
| }>; | ||
|
|
||
| async function deleteServiceGroups() { |
Member
There was a problem hiding this comment.
Suggested change
| async function deleteServiceGroups() { | |
| async function deleteAllServiceGroups() { |
sorenlouv
reviewed
Dec 1, 2022
Comment on lines
+65
to
+73
| const response = await supertest | ||
| .get('/api/saved_objects/_find?type=apm-service-group') | ||
| .set('kbn-xsrf', 'true'); | ||
| const savedObjects: SavedObjectsFindResults = response.body.saved_objects; | ||
| const bulkDeleteBody = savedObjects.map(({ id, type }) => ({ id, type })); | ||
| return supertest | ||
| .post(`/api/saved_objects/_bulk_delete?force=true`) | ||
| .set('kbn-xsrf', 'true') | ||
| .send(bulkDeleteBody); |
Member
There was a problem hiding this comment.
Unless it is much slower, we should use our own APIs.
To retrieve all service groups:
GET /internal/apm/service-groups
Then, to delete a service group:
DELETE /internal/apm/service-group
Contributor
There was a problem hiding this comment.
Yes, makes sense, I used our own for the e2e tests
sorenlouv
reviewed
Dec 1, 2022
Comment on lines
+77
to
+149
| let synthbeansServiceGroupId: string; | ||
| let opbeansServiceGroupId: string; | ||
| before(async () => { | ||
| const synthServices = [ | ||
| apm | ||
| .service({ name: 'synth-go', environment: 'testing', agentName: 'go' }) | ||
| .instance('instance-1'), | ||
| apm | ||
| .service({ name: 'synth-java', environment: 'testing', agentName: 'java' }) | ||
| .instance('instance-2'), | ||
| apm | ||
| .service({ name: 'opbeans-node', environment: 'testing', agentName: 'nodejs' }) | ||
| .instance('instance-3'), | ||
| ]; | ||
|
|
||
| const [, { body: synthbeansServiceGroup }, { body: opbeansServiceGroup }] = await Promise.all( | ||
| [ | ||
| synthtraceEsClient.index( | ||
| synthServices.map((service) => | ||
| timerange(start, end) | ||
| .interval('5m') | ||
| .rate(1) | ||
| .generator((timestamp) => | ||
| service | ||
| .transaction({ | ||
| transactionName: 'GET /api/product/list', | ||
| transactionType: 'request', | ||
| }) | ||
| .duration(2000) | ||
| .timestamp(timestamp) | ||
| .children( | ||
| service | ||
| .span({ | ||
| spanName: '/_search', | ||
| spanType: 'db', | ||
| spanSubtype: 'elasticsearch', | ||
| }) | ||
| .destination('elasticsearch') | ||
| .duration(100) | ||
| .success() | ||
| .timestamp(timestamp), | ||
| service | ||
| .span({ | ||
| spanName: '/_search', | ||
| spanType: 'db', | ||
| spanSubtype: 'elasticsearch', | ||
| }) | ||
| .destination('elasticsearch') | ||
| .duration(300) | ||
| .success() | ||
| .timestamp(timestamp) | ||
| ) | ||
| .errors( | ||
| service.error({ message: 'error 1', type: 'foo' }).timestamp(timestamp), | ||
| service.error({ message: 'error 2', type: 'foo' }).timestamp(timestamp), | ||
| service.error({ message: 'error 3', type: 'bar' }).timestamp(timestamp) | ||
| ) | ||
| ) | ||
| ) | ||
| ), | ||
| saveServiceGroup({ | ||
| groupName: 'synthbeans', | ||
| kuery: 'service.name: synth*', | ||
| }), | ||
| saveServiceGroup({ | ||
| groupName: 'opbeans', | ||
| kuery: 'service.name: opbeans*', | ||
| }), | ||
| ] | ||
| ); | ||
| synthbeansServiceGroupId = synthbeansServiceGroup.id; | ||
| opbeansServiceGroupId = opbeansServiceGroup.id; | ||
| }); |
Member
There was a problem hiding this comment.
We normally extract this outside the test to reduce noise. Can we do the same here? Perhaps create a folder service_group_count with both the test and the data generation function
sorenlouv
reviewed
Dec 1, 2022
Comment on lines
+167
to
+189
| const { body: createdRule } = await supertest | ||
| .post(`/api/alerting/rule`) | ||
| .set('kbn-xsrf', 'true') | ||
| .send({ | ||
| params: { | ||
| serviceName: 'synth-go', | ||
| transactionType: '', | ||
| windowSize: 99, | ||
| windowUnit: 'y', | ||
| threshold: 100, | ||
| aggregationType: 'avg', | ||
| environment: 'testing', | ||
| }, | ||
| consumer: 'apm', | ||
| schedule: { interval: '1m' }, | ||
| tags: ['apm'], | ||
| name: 'Latency threshold | synth-go', | ||
| rule_type_id: ApmRuleType.TransactionDuration, | ||
| notify_when: 'onActiveAlert', | ||
| actions: [], | ||
| }); | ||
| ruleId = createdRule.id; | ||
| await waitForActiveAlert({ ruleId, esClient, log }); |
Member
There was a problem hiding this comment.
Extract this to createRule function
sorenlouv
reviewed
Dec 1, 2022
Comment on lines
+64
to
+70
| await delay(WAIT_FOR_STATUS_INCREMENT); | ||
| return await waitForActiveAlert({ | ||
| ruleId, | ||
| waitMillis: waitMillis - WAIT_FOR_STATUS_INCREMENT, | ||
| esClient, | ||
| log, | ||
| }); |
Member
There was a problem hiding this comment.
Can you remove this custom retry logic, and instead use p-retry. Perhaps with a factor of 1 (instead of 2).
sorenlouv
reviewed
Dec 1, 2022
x-pack/test/apm_api_integration/tests/service_groups/wait_for_active_alert.ts
Show resolved
Hide resolved
…groups-alert-count
sorenlouv
reviewed
Dec 2, 2022
Comment on lines
+37
to
+38
| index: apmAlertsIndices.join(','), | ||
| ...searchParams, |
Member
There was a problem hiding this comment.
Let's change the order of this so it's not possible to override index
Suggested change
| index: apmAlertsIndices.join(','), | |
| ...searchParams, | |
| ...searchParams, | |
| index: apmAlertsIndices.join(','), |
sorenlouv
reviewed
Dec 2, 2022
Member
There was a problem hiding this comment.
Suggested change
| return promises; | |
| return Promise.all(promises); |
sorenlouv
reviewed
Dec 2, 2022
Member
There was a problem hiding this comment.
Suggested change
| return promises; | |
| return Promise.all(promises); |
Member
There was a problem hiding this comment.
Btw can you extract deleteAllServiceGroups so we don't duplicate it
MiriamAparicio
force-pushed
the
apm-143613-service-groups-alert-count
branch
from
600f7e7 to
0085041
Compare
💚 Build Succeeded
Metrics [docs]Async chunks
Unknown metric groupsESLint disabled in files
ESLint disabled line counts
Total ESLint disabled count
History
To update your PR or re-run it, just comment with: |
This file contains hidden or bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
Sign up for free
to join this conversation on GitHub.
Already have an account?
Sign in to comment
13 participants
Add this suggestion to a batch that can be applied as a single commit.This suggestion is invalid because no changes were made to the code.Suggestions cannot be applied while the pull request is closed.Suggestions cannot be applied while viewing a subset of changes.Only one suggestion per line can be applied in a batch.Add this suggestion to a batch that can be applied as a single commit.Applying suggestions on deleted lines is not supported.You must change the existing code in this line in order to create a valid suggestion.Outdated suggestions cannot be applied.This suggestion has been applied or marked resolved.Suggestions cannot be applied from pending reviews.Suggestions cannot be applied on multi-line comments.Suggestions cannot be applied while the pull request is queued to merge.Suggestion cannot be applied right now. Please check back later.
Closes #143613
Closes #144420
