If you find Pincode useful, please give it a 🌟

Pincode

Screenshot

GetingStarted

In your build.gradle:

		compile 'mm.mlika.android:pincode2:5.3'

In xml:

		<mlikamohamed.com.pincode.PinCode
		xmlns:pin="http://schemas.android.com/apk/res-auto"
		android:layout_width="wrap_content"
		android:inputType="textVisiblePassword"
		android:layout_height="wrap_content"/>

the xml android:inputType="textVisiblePassword" to remove suggestion

if you want to only accept numbers

In xml:

		<mlikamohamed.com.pincode.PinCode
		xmlns:pin="http://schemas.android.com/apk/res-auto"
		android:layout_width="wrap_content"
		android:inputType="textVisiblePassword|number"
		android:digits="0123456789"
		android:layout_height="wrap_content"/>

set box count

by default it is 4

In xml:

		pin:boxCount="4"

In java:

		PinCode pinCode = findViewById(R.id.pinCode);
		pinCode.setBoxCount(5);

box width and height

by default 38dp

In xml:

		pin:boxWidthAndHeight="40dp"

In java:

		PinCode pinCode = findViewById(R.id.pinCode);
		pinCode.setBoxWidthAndHeight(40); // width and height is 40 pixel
		pinCode.setBoxWidthAndHeightDP(40); // width and height is 40 dp

change box color

by default the color is grey

In xml:

		pin:boxColor="@color/colorAccent"

In java:

		pinCode.setBoxColor(ContextCompat.getColor(this,R.color.colorAccent));

change Highlighted box color

by default the color is black

In xml:

		pin:highlightedBoxColor="@color/colorPrimary"

In java:

		pinCode.setHighlightedBoxColor(ContextCompat.getColor(this,R.color.colorPrimary));

change box stroke width

by default the width is 1 dp

In xml:

		pin:strokeWidth="2dp"

In java:

		pinCode.setStrokeWidth(2); // the width is 2 pixel
        pinCode.setStrokeWidthDP(2); // the width is 2 dp

change margin between boxes

by default the margin between boxes is 10dp

In xml:

		pin:marginBetweenBox="5dp"

In java:

		pinCode.setMarginBetweenBox(10); // 10px
		pinCode.setMarginBetweenBoxDp(10); // 10dp

show text

In java:

		PinCode pinCode = findViewById(R.id.pinCode);
		pinCode.showText();
		pinCode.isTextVisible(); // return true

hide text

In java:

		PinCode pinCode = findViewById(R.id.pinCode);
		pinCode.hideText();
		pinCode.isTextVisible(); // return false

change text size

by default the size of the text is 18dp

In xml:

		pin:textSize="30dp"

In java:

		pinCode.setTextSize(17); // text size 17 px
		pinCode.setTextSizeDP(17); // text size 17 dp

change text color

by default the color is black

In xml:

		pin:boxColor="@color/colorAccent"

In java:

		pinCode.setTextColor(ContextCompat.getColor(this,R.color.colorPrimary));

change picture

In xml:

		pin:imageResource="@drawable/icon_google"

In java:

		PinCode pinCode = findViewById(R.id.pinCode);
		pinCode.setImageResource(R.drawable.icon_google);

value change listener

In xml:

In java:

		PinCode pinCode = findViewById(R.id.pinCode);
		pinCode.setTextChangeListener(new PinCode.OnTextChangeListener() {
		@Override
		public void onTextChanged(String text) {
                // this method will be called when text change
		}


		@Override
		public void onAllBoxFilled(String text) {
				// this method will be called when all boxes are filled
}
		});
