ZooKeeper 的 Watcher 机制,总的来说可以分为三个过程:客户端注册 Watcher、 服务器处理 Watcher 和客户端回调 Watcher
客户端注册 watcher 有 3 种方式,getData、exists、getChildren;以如下代码为例 来分析整个触发机制的原理
public class Test implements Watcher{
static ZooKeeper zooKeeper;
static {
try {
zooKeeper = new ZooKeeper("localhost:2181", 4000,new Test());
} catch (IOException e) {
e.printStackTrace();
}
}
@Override
public void process(WatchedEvent event) {
System.out.println("eventType:"+event.getType());
if(event.getType()==Event.EventType.NodeDataChanged){
try {
zooKeeper.exists(event.getPath(),true);
} catch (KeeperException e) {
e.printStackTrace();
} catch (InterruptedException e) {
e.printStackTrace();
}
}
}
//getData()/ exists /getChildren
public static void main(String[] args) throws IOException, KeeperException, InterruptedException {
//Curator
String path="/watcher";
if(zooKeeper.exists(path,false)==null) {
zooKeeper.create("/watcher", "0".getBytes(), ZooDefs.Ids.OPEN_ACL_UNSAFE, CreateMode.PERSISTENT);
}
Thread.sleep(1000);
System.out.println("-----------");
Stat stat=zooKeeper.exists(path,true); //true表示使用zookeeper实例中配置的watcher
System.in.read();
}
}
在创建一个 ZooKeeper 客户端对象实例时,我们通过 new Watcher()向构造方法中 传入一个默认的 Watcher, 这个 Watcher 将作为整个 ZooKeeper 会话期间的默认 Watcher,会一直被保存在客户端 ZKWatchManager 的 defaultWatcher 中;代码如 下
public ZooKeeper(String connectString, int sessionTimeout, Watcher watcher,
boolean canBeReadOnly)
throws IOException
{
LOG.info("Initiating client connection, connectString=" + connectString
+ " sessionTimeout=" + sessionTimeout + " watcher=" + watcher);
watchManager.defaultWatcher = watcher;
ConnectStringParser connectStringParser = new ConnectStringParser(
connectString);
HostProvider hostProvider = new StaticHostProvider(
connectStringParser.getServerAddresses());
cnxn = new ClientCnxn(connectStringParser.getChrootPath(),
hostProvider, sessionTimeout, this, watchManager,
getClientCnxnSocket(), canBeReadOnly);
cnxn.start();
}
ClientCnxn:是 Zookeeper 客户端和 Zookeeper 服务器端进行通信和事件通知处理 的主要类,它内部包含两个类,
1.SendThread :负责客户端和服务器端的数据通信, 也包括事件信息的传输
2.EventThread : 主要在客户端回调注册的 Watchers 进行通知处理
public ClientCnxn(String chrootPath, HostProvider hostProvider, int sessionTimeout, ZooKeeper zooKeeper,
ClientWatchManager watcher, ClientCnxnSocket clientCnxnSocket,
long sessionId, byte[] sessionPasswd, boolean canBeReadOnly) {
this.zooKeeper = zooKeeper;
this.watcher = watcher;
this.sessionId = sessionId;
this.sessionPasswd = sessionPasswd;
this.sessionTimeout = sessionTimeout;
this.hostProvider = hostProvider;
this.chrootPath = chrootPath;
connectTimeout = sessionTimeout / hostProvider.size();
readTimeout = sessionTimeout * 2 / 3;
readOnly = canBeReadOnly;
sendThread = new SendThread(clientCnxnSocket);
eventThread = new EventThread();
}
public void start() { --启动两个线程
sendThread.start();
eventThread.start();
}
