Leaflet 1.x and 2.x plugin, Leaflet-tilelayer-mask adds mask effect to tilelayer. Older version for Leaflet 0.7.x is available here.
- https://frogcat.github.io/leaflet-tilelayer-mask/ (Leaflet 1.x)
- https://frogcat.github.io/leaflet-tilelayer-mask/TileLayerWithMask.html (Leaflet 2.x)
// Create map
var map = L.map("map", {
zoom : ...,
center : ...
});
// Add background tile layer
L.tileLayer(...).addTo(map);
// Create foreground tile layer with mask
var fg = L.tileLayer.mask('https://aginfo.cgk.affrc.go.jp/ws/tmc/1.0.0/Kanto_Rapid-900913-L/{z}/{x}/{y}.jpg', {
maskUrl : 'star.png', // optional
maskSize : 1024 //optional
).addTo(map);
// Add event handler to update mask position
map.on("mousemove", function(e) {
fg.setCenter(e.containerPoint);
});| Option | Type | Default | Description |
|---|---|---|---|
| maskUrl | String | #1 | Url of mask image |
| maskSize | L.point or Number | L.point(512,512) | mask size |
| Method | Returns | Description |
|---|---|---|
| setCenter(Number x, Number y) | this | Set the mask center relative to map container. |
| setCenter(Point p) | this | Expects a L.Point object instead |
- Leaflet-tilelayer-mask depends on SVG mask.
leaflet-tilelayer-mask.js has been rewritten as TileLayerWithMask.js, an ES Module for Leaflet 2.0.
<!DOCTYPE html>
<html>
<head>
<meta charset="UTF-8" />
<title>TileLayerWithMask for leaflet 2.0.0-alpha.1</title>
<meta name="viewport" content="initial-scale=1.0, maximum-scale=1.0" />
<link href="https://unpkg.com/[email protected]/dist/leaflet.css" rel="stylesheet" />
<script type="importmap">
{
"imports": {
"leaflet": "https://unpkg.com/[email protected]/dist/leaflet.js",
"mask": "https://frogcat.github.io/leaflet-tilelayer-mask/TileLayerWithMask.js"
}
}
</script>
</head>
<body>
<div id="map" style="position: absolute; top: 0; left: 0; right: 0; bottom: 0"></div>
<script type="module">
import { Map, TileLayer } from "leaflet";
import TileLayerWithMask from "mask";
const map = new Map("map").setView([35.6323, 139.768815], 15);
new TileLayer("https://cyberjapandata.gsi.go.jp/xyz/pale/{z}/{x}/{y}.png", {
maxZoom: 18,
attribution: '<a href="https://maps.gsi.go.jp/development/ichiran.html">GSI pale</a>',
}).addTo(map);
const mask = new TileLayerWithMask(
"https://cyberjapandata.gsi.go.jp/xyz/seamlessphoto/{z}/{x}/{y}.jpg",
{
maxZoom: 18,
attribution:
'<a href="https://maps.gsi.go.jp/development/ichiran.html">GSI seamlessphoto</a>',
maskSize: 800,
}
).addTo(map);
map.on("pointermove", function (e) {
mask.setCenter(e.containerPoint);
});
</script>
</body>
</html>
