The git plugin provides fundamental git operations for Jenkins projects. It can poll, fetch, checkout, branch, list, merge, tag, and push repositories.
Changelog in GitHub Releases
Release notes are recorded in GitHub Releases since July 1, 2019 (git plugin 3.10.1 and later). Prior release notes are recorded in the git plugin repository change log.
The git plugin provides an SCM implementation to be used with the Pipeline SCM checkout step.
The Pipeline Syntax Snippet Generator guides the user to select checkout options.
The 90 second video clip below introduces the Pipeline Syntax Snippet Generator and shows how it is used to generate steps for the Jenkins Pipeline.
The git plugin includes a multibranch provider for Jenkins Multibranch Pipelines and for Jenkins Organization Folders. The git plugin multibranch provider is a "base implementation" that uses command line git. Users should prefer the multibranch implementation for their git provider when one is available. Multibranch implementations for specific git providers can use REST API calls to improve the Jenkins experience and add additional capabilities. Multibranch implementations are available for GitHub, Bitbucket, GitLab, Gitea, and Tuleap.
The 30 minute video clip below introduces Multibranch Pipelines.
The git plugin provides Git Username and Password binding that allows authenticated git operations over HTTP and HTTPS protocols using command line git in a Pipeline job.
The git credential bindings are accessible through the withCredentials step of the Credentials Binding plugin.
The binding retrieves credentials from the Credentials plugin.
This binding provides authentication support over HTTP protocol using command line git in a Pipeline job.
- Procedure
-
-
Click the Pipeline Syntax Snippet Generator and choose the
withCredentialsstep, add Git Username and Password binding. -
Choose the required credentials and Git tool name, specific to the generated Pipeline snippet.
-
Two variable bindings are used, GIT_USERNAME and GIT_PASSWORD, to pass the username and password to sh, bat, and powershell steps inside the withCredentials block of a Pipeline job.
The variable bindings are available even if the JGit or JGit with Apache HTTP Client git implementation is being used.
withCredentials([gitUsernamePassword(credentialsId: 'my-credentials-id',
gitToolName: 'git-tool')]) {
sh 'git fetch --all'
}withCredentials([gitUsernamePassword(credentialsId: 'my-credentials-id',
gitToolName: 'git-tool')]) {
bat 'git submodule update --init --recursive'
}withCredentials([gitUsernamePassword(credentialsId: 'my-credentials-id',
gitToolName: 'git-tool')]) {
powershell 'git push'
}
The git plugin fetches commits from one or more remote repositories and performs a checkout in the agent workspace. Repositories and their related information include:
- Repository URL
-
The URL of the remote repository. The git plugin passes the remote repository URL to the git implementation (command line or JGit). Valid repository URL’s include
https,ssh,scp,git,local file, and other forms. Valid repository URL forms are described in the git documentation. - Credentials
-
Credentials are defined using the Jenkins credentials plugin. They are selected from a drop-down list and their identifier is stored in the job definition. Refer to using credentials for more details on supported credential types.
- Name
-
Git uses a short name to simplify user references to the URL of the remote repository. The default short name is
origin. Other values may be assigned and then used throughout the job definition to refer to the remote repository. - Refspec
-
A refspec maps remote branches to local references. It defines the branches and tags which will be fetched from the remote repository into the agent workspace.
A refspec defines the remote references that will be retrieved and how they map to local references. If left blank, it will default to the normal
git fetchbehavior and will retrieve all branches. This default behavior is sufficient for most cases.The default refspec is
+refs/heads/*:refs/remotes/REPOSITORYNAME/where REPOSITORYNAME is the value you specify in the above repository "Name" field. The default refspec retrieves all branches. If a checkout only needs one branch, then a more restrictive refspec can reduce the data transfer from the remote repository to the agent workspace. For example,+refs/heads/master:refs/remotes/origin/masterwill retrieve only the master branch and nothing else.The refspec can be used with the honor refspec on initial clone option in the advanced clone behaviors to limit the number of remote branches mapped to local references. If "honor refspec on initial clone" is not enabled, then a default refspec for its initial fetch. This maintains compatibility with previous behavior and allows the job definition to decide if the refspec should be honored on initial clone.
Multiple refspecs can be entered by separating them with a space character. The refspec value
+refs/heads/master:refs/remotes/origin/master +refs/heads/develop:refs/remotes/origin/developretrieves the master branch and the develop branch and nothing else.Refer to the git refspec documentation for more refspec details.
The git plugin supports username / password credentials and private key credentials provided by the Jenkins credentials plugin. It does not support other credential types like secret text, secret file, or certificates. Select credentials from the job definition drop down menu or enter their identifiers in Pipeline job definitions.
When the remote repository is accessed with the HTTP or HTTPS protocols, the plugin requires a username / password credential. Other credential types will not work with HTTP or HTTPS protocols.
When the remote repository is accessed with the ssh protocol, the plugin requires an ssh private key credential. Other credential types will not work with the ssh protocol.
To minimize the delay between a push and a build, configure the remote repository to use a Webhook to notify Jenkins of changes to the repository. Refer to webhook documentation for your repository:
Other git repositories can use a post-receive hook in the remote repository to notify Jenkins of changes.
Add the following line in your hooks/post-receive file on the git server, replacing <URL of the Git repository> with the fully qualified URL you use when cloning the repository.
curl http://yourserver/git/notifyCommit?url=<URL of the Git repository>
This will scan all the jobs that:
-
Have Build Triggers > Poll SCM enabled. No polling schedule is required.
-
Are configured to build the repository at the specified URL
For jobs that meet these conditions, polling will be triggered. If polling finds a change worthy of a build, a build will be triggered.
This allows a notify script to remain the same for all Jenkins jobs. Or if you have multiple repositories under a single repository host application (such as Gitosis), you can share a single post-receive hook script with all the repositories. Finally, this URL doesn’t require authentication even for secured Jenkins, because the server doesn’t directly use anything that the client is sending. It polls to verify that there is a change before it actually starts a build.
When notifyCommit is successful, the list of triggered projects is returned.
See the git client plugin documentation for instructions to enable JGit. JGit becomes available throughout Jenkins once it has been enabled.
In the Configure System page, the Git Plugin provides the following options:
- Global Config user.name Value
-
Defines the default git user name that will be assigned when git commits a change from Jenkins. For example,
Janice Examplesperson. This can be overridden by individual projects with the Custom user name/e-mail address extension.
- Global Config user.email Value
-
Defines the default git user e-mail that will be assigned when git commits a change from Jenkins. For example,
[email protected]. This can be overridden by individual projects with the Custom user name/e-mail address extension.
- Show the entire commit summary in changes
-
The
changespage for each job would truncate the change summary prior to git plugin 4.0. With the release of git plugin 4.0, the default was changed to show the complete change summary. Administrators that want to restore the old behavior may disable this setting.
- Hide credential usage in job output
-
If checked, the console log will not show the credential identifier used to clone a repository.
- Disable performance enhancements
-
If JGit and command line git are both enabled on an agent, the git plugin uses a "git tool chooser" to choose a preferred git implementation. The preferred git implementation depends on the size of the repository and the git plugin features requested by the job. If the repository size is less than the JGit repository size threshold and the git features of the job are all implemented in JGit, then JGit is used. If the repository size is greater than the JGit repository size threshold or the job requires git features that are not implemented in JGit, then command line git is used.
If checked, the plugin will disable the feature that recommends a git implementation on the basis of the size of a repository. This switch may be used in case of a bug in the performance improvement feature. If you enable this setting, please report a git plugin issue that describes why you needed to enable it.
- Preserve second fetch during initial checkout
-
If checked, the initial checkout step will not avoid the second fetch. Git plugin versions prior to git plugin 4.4 would perform two fetch operations during the initial repository checkout. Git plugin 4.4 removes the second fetch operation in most cases. Enabling this option will restore the second fetch operation. This setting is only needed if there is a bug in the redundant fetch removal logic. If you enable this setting, please report a git plugin issue that describes why you needed to enable it.
- Add git tag action to jobs
-
If checked, the git tag action will be added to any builds that happen after the box is checked. Prior to git plugin 4.5.0, the git tag action was always added. Git plugin 4.5.0 and later will not add the git tag action to new builds unless the administrator enables it.
The git tag action allows a user to apply a tag to the git repository in the workspace based on the git commit used in the build applying the tag. The git plugin does not push the applied tag to any other location. If the workspace is removed, the tag that was applied is lost. Tagging a workspace made sense when using centralized repositories that automatically applied the tag to the centralized repository. Applying a git tag in an agent workspace doesn’t have many practical uses.
A Repository Browser adds links in "changes" views within Jenkins to an external system for browsing the details of those changes. The "Auto" selection attempts to infer the repository browser from the "Repository URL" and can detect cloud versions of GitHub, Bitbucket and GitLab.
Repository browsers include:
Repository browser for git repositories hosted by Assembla. Options include:
- Assembla Git URL
-
Root URL serving this Assembla repository. For example,
https://app.assembla.com/spaces/git-plugin/git/source
Repository browser for git repositories hosted by Atlassian Fisheye. Options include:
- URL
-
Root URL serving this FishEye repository. For example,
https://fisheye.example.com/browser/my-project
Repository browser for git repositories hosted by Kiln. Options include:
- URL
-
Root URL serving this Kiln repository. For example,
https://kiln.example.com/username/my-project
Repository browser for git repositories hosted by Azure DevOps. Options include:
- URL or name
-
Root URL serving this Azure DevOps repository. For example,
https://example.visualstudio.com/_git/my-project.
Repository browser for git repositories hosted by Bitbucket. Options include:
- URL
-
Root URL serving this Bitbucket repository. For example,
https://bitbucket.example.com/username/my-project
Repository browser for git repositories hosted by an on-premises Bitbucket Server installation. Options include:
- URL
-
Root URL serving this Bitbucket repository. For example,
https://bitbucket-server:7990/username/my-project
Repository browser for git repositories hosted by cgit. Options include:
- URL
-
Root URL serving this cgit repository. For example,
https://git.zx2c4.com/cgit/
- GitBlit root url
-
Root URL serving this GitBlit repository. For example,
https://gitblit.example.com/
- Project name in GitBlit
-
Name of the GitBlit project. For example,
my-project
Repository browser for git repositories hosted by GitHub. Options include:
- URL
-
Root URL serving this GitHub repository. For example,
https://github.example.com/username/my-project
Repository browser for git repositories hosted by Gitiles. Options include:
- gitiles root url
-
Root URL serving this Gitiles repository. For example,
https://gerrit.googlesource.com/gitiles/
Repository browser for git repositories hosted by GitLab. Options include:
- URL
-
Root URL serving this GitLab repository. For example,
https://gitlab.example.com/username/my-project
- Version
-
Major and minor version of GitLab you use, such as 12.6. If you don’t specify a version, a modern version of GitLab (>= 8.0) is assumed. For example,
12.6
Repository browser for git repositories hosted by GitList. Options include:
- URL
-
Root URL serving this GitList repository. For example,
https://gitlist.example.com/username/my-project
Gitorious was acquired in 2015. This browser is deprecated.
- URL
-
Root URL serving this Gitorious repository. For example,
https://gitorious.org/username/my-project
Repository browser for git repositories hosted by GitWeb. Options include:
- URL
-
Root URL serving this GitWeb repository. For example,
https://gitweb.example.com/username/my-project
Repository browser for git repositories hosted by Gogs. Options include:
- URL
-
Root URL serving this Gogs repository. For example,
https://gogs.example.com/username/my-project
Repository browser for git repositories hosted by Phacility Phabricator. Options include:
- URL
-
Root URL serving this Phabricator repository. For example,
https://phabricator.example.com/
- Repository name in Phab
-
Name of the Phabricator repository. For example,
my-project
Repository browser for git repositories hosted by Redmine. Options include:
- URL
-
Root URL serving this Redmine repository. For example,
https://redmine.example.com/username/projects/my-project/repository
Repository browser for git repositories hosted by RhodeCode. Options include:
- URL
-
Root URL serving this RhodeCode repository. For example,
https://rhodecode.example.com/username/my-project
Stash is now called BitBucket Server. Repository browser for git repositories hosted by BitBucket Server. Options include:
- URL
-
Root URL serving this Stash repository. For example,
https://stash.example.com/username/my-project
Repository browser for git repositories hosted by viewgit. Options include:
- ViewGit root url
-
Root URL serving this ViewGit repository. For example,
https://viewgit.example.com/
- Project Name in ViewGit
-
ViewGit project name. For example,
my-project
The git plugin provides one binding to support authenticated git operations over HTTP or HTTPS protocol, namely Git Username and Password.
The git plugin depends on the Credential Binding Plugin to support these bindings.
To access the Git Username and Password binding in a Pipeline job, visit Git Credentials Binding
Freestyle projects can use git credential binding with the following steps:
-
Check the box Use secret text(s) or file(s), add Git Username and Password binding.
-
Choose the required credentials and Git tool name.
Two variable bindings are used, GIT_USERNAME and GIT_PASSWORD, to pass the username and password to shell, batch, and powershell steps in a Freestyle job.
The variable bindings are available even if the JGit or JGit with Apache HTTP Client git implementation is being used.
Extensions add new behavior or modify existing plugin behavior for different uses. Extensions help users more precisely tune the plugin to meet their needs.
Extensions include:
Clone extensions modify the git operations that retrieve remote changes into the agent workspace. The extensions can adjust the amount of history retrieved, how long the retrieval is allowed to run, and other retrieval details.
-
breadth of history retrieval (refspecs)
-
depth of history retrieval (shallow clone)
-
disc space use (reference repositories)
-
duration of the command (timeout)
-
tag retrieval
Advanced clone behaviors include:
- Honor refspec on initial clone
-
Perform initial clone using the refspec defined for the repository. This can save time, data transfer and disk space when you only need to access the references specified by the refspec. If this is not enabled, then the plugin default refspec includes all remote branches.
- Shallow clone
-
Perform a shallow clone by requesting a limited number of commits from the tip of the requested branch(es). Git will not download the complete history of the project. This can save time and disk space when you just want to access the latest version of a repository.
- Shallow clone depth
-
Set shallow clone depth to the specified number of commits. Git will only download
depthcommits from the remote repository, saving time and disk space. - Path of the reference repo to use during clone
-
Specify a folder containing a repository that will be used by git as a reference during clone operations. This option will be ignored if the folder is not available on the agent.
- Timeout (in minutes) for clone and fetch operations
-
Specify a timeout (in minutes) for clone and fetch operations.
- Fetch tags
-
Deselect this to perform a clone without tags, saving time and disk space when you want to access only what is specified by the refspec, without considering any repository tags.
Removes remote tracking branches from the local workspace if they no longer exist on the remote.
See git remote prune and git fetch --prune for more details.
Removes tags from the local workspace before fetch if they no longer exist on the remote. If stale tags are not pruned, deletion of a remote tag will not remove the local tag in the workspace. If the local tag already exists in the workspace, git correctly refuses to create the tag again. Pruning stale tags allows the local workspace to create a tag with the same name as a tag which was removed from the remote.
Checkout extensions modify the git operations that place files in the workspace from the git repository on the agent. The extensions can adjust the maximum duration of the checkout operation, the use and behavior of git submodules, the location of the workspace on the disc, and more.
Advanced checkout behaviors modify the git checkout command.
Advanced checkout behaviors include
- Timeout (in minutes) for checkout operation
-
Specify a timeout (in minutes) for checkout. The checkout is stopped if the timeout is exceeded. Checkout timeout is usually only required with slow file systems or large repositories.
Advanced sub-modules behaviors modify the git submodule commands.
They control:
-
depth of history retrieval (shallow clone)
-
disc space use (reference repositories)
-
credential use
-
duration of the command (timeout)
-
concurrent threads used to fetch submodules
Advanced sub-modules include:
- Disable submodules processing
-
Ignore submodules in the repository.
- Recursively update submodules
-
Retrieve all submodules recursively. Without this option, submodules which contain other submodules will ignore the contained submodules.
- Update tracking submodules to tip of branch
-
Retrieve the tip of the configured branch in .gitmodules.
- Use credentials from default remote of parent repository
-
Use credentials from the default remote of the parent project. Submodule updates do not use credentials by default. Enabling this extension will provide the parent repository credentials to each of the submodule repositories. Submodule credentials require that the submodule repository must accept the same credentials as the parent project. If the parent project is cloned with https, then the authenticated submodule references must use https as well. If the parent project is cloned with ssh, then the authenticated submodule references must use ssh as well.
- Path of the reference repo to use during submodule update
-
Folder containing a repository that will be used by git as a reference during submodule clone operations. This option will be ignored if the folder is not available on the agent running the build. A reference repository may contain multiple subprojects. See the combining repositories section for more details.
- Timeout (in minutes) for submodule operations
-
Specify a timeout (in minutes) for submodules operations. This option overrides the default timeout.
- Number of threads to use when updating submodules
-
Number of parallel processes to be used when updating submodules. Default is to use a single thread for submodule updates
- Shallow clone
-
Perform shallow clone of submodules. Git will not download the complete history of the project, saving time and disk space.
- Shallow clone depth
-
Set shallow clone depth for submodules. Git will only download recent history of the project, saving time and disk space.
Checkout to a subdirectory of the workspace instead of using the workspace root.
This extension should not be used in Jenkins Pipeline (either declarative or scripted).
Jenkins Pipeline already provides standard techniques for checkout to a subdirectory.
Use ws and dir in Jenkins Pipeline rather than this extension.
- Local subdirectory for repo
-
Name of the local directory (relative to the workspace root) for the git repository checkout. If left empty, the workspace root itself will be used.
- Branch name
-
If given, checkout the revision to build as HEAD on the named branch. If value is an empty string or "**", then the branch name is computed from the remote branch without the origin. In that case, a remote branch 'origin/master' will be checked out to a local branch named 'master', and a remote branch 'origin/develop/new-feature' will be checked out to a local branch named 'develop/new-feature'. If a specific revision and not branch HEAD is checked out, then 'detached' will be used as the local branch name.
Delete the contents of the workspace before build and before checkout. Deletes the git repository inside the workspace and will force a full clone.
Clean the workspace after every checkout by deleting all untracked files and directories, including those which are specified in .gitignore.
Resets all tracked files to their versioned state.
Ensures that the workspace is in the same state as if clone and checkout were performed in a new workspace.
Reduces the risk that current build will be affected by files generated by prior builds.
Does not remove files outside the workspace (like temporary files or cache files).
Does not remove files in the .git repository of the workspace.
- Delete untracked nested repositories
-
Remove subdirectories which contain
.gitsubdirectories if this option is enabled. This is implemented in command line git asgit clean -xffd. Refer to the git clean manual page for more information.
Clean the workspace before every checkout by deleting all untracked files and directories, including those which are specified in .gitignore.
Resets all tracked files to their versioned state.
Ensures that the workspace is in the same state as if cloned and checkout were performed in a new workspace.
Reduces the risk that current build will be affected by files generated by prior builds.
Does not remove files outside the workspace (like temporary files or cache files).
Does not remove files in the .git repository of the workspace.
- Delete untracked nested repositories
-
Remove subdirectories which contain
.gitsubdirectories if this option is enabled. This is implemented in command line git asgit clean -xffd. Refer to the git clean manual page for more information.
Specify the paths that you’d like to sparse checkout. This may be used for saving space (Think about a reference repository). Be sure to use a recent version of Git, at least above 1.7.10.
Multiple sparse checkout path values can be added to a single job.
- Path
-
File or directory to be included in the checkout
Enable git large file support for the workspace by pulling large files after the checkout completes.
Requires that the controller and each agent performing an LFS checkout have installed git lfs.
The plugin can calculate the source code differences between two builds. Changelog extensions adapt the changelog calculations for different cases.
'Calculate changelog against a specific branch' uses the specified branch to compute the changelog instead of computing it based on the previous build. This extension can be useful for computing changes related to a known base branch, especially in environments which do not have the concept of a "pull request".
- Name of repository
-
Name of the repository, such as 'origin', that contains the branch.
- Name of branch
-
Name of the branch used for the changelog calculation within the named repository.
Tagging extensions allow the plugin to apply tags in the current workspace.
The git plugin can start builds based on many different conditions. The build initiation extensions control the conditions that start a build. They can ignore notifications of a change or force a deeper evaluation of the commits when polling
If checked, this repository will be ignored when the notifyCommit URL is accessed whether the repository matches or not.
The git plugin polls remotely using ls-remote when configured with a single branch (no wildcards!).
When this extension is enabled, the polling is performed from a cloned copy of the workspace instead of using ls-remote.
If this option is selected, polling will use a workspace instead of using ls-remote.
By default, the plugin polls by executing a polling process or thread on the Jenkins controller. If the Jenkins controller does not have a git installation, the administrator may enable JGit to use a pure Java git implementation for polling. In addition, the administrator may need to disable command line git to prevent use of command line git on the Jenkins controller.
These options allow you to perform a merge to a particular branch before building. For example, you could specify an integration branch to be built, and to merge to master. In this scenario, on every change of integration, Jenkins will perform a merge with the master branch, and try to perform a build if the merge is successful. It then may push the merge back to the remote repository if the Git Push post-build action is selected.
- Excluded Users
-
If set and Jenkins is configured to poll for changes, Jenkins will ignore any revisions committed by users in this list when determining if a build should be triggered. This can be used to exclude commits done by the build itself from triggering another build, assuming the build server commits the change with a distinct SCM user. Using this behavior prevents the faster
git ls-remotepolling mechanism. It forces polling to require a workspace, as if you had selected the Force polling using workspace extension.Each exclusion uses exact string comparison and must be separated by a new line. User names are only excluded if they exactly match one of the names in this list.
If set and Jenkins is configured to poll for changes, Jenkins will pay attention to included and/or excluded files and/or folders when determining if a build needs to be triggered.
Using this behavior will preclude the faster remote polling mechanism, forcing polling to require a workspace thus sometimes triggering unwanted builds, as if you had selected the Force polling using workspace extension as well. This can be used to exclude commits done by the build itself from triggering another build, assuming the build server commits the change with a distinct SCM user. Using this behavior will preclude the faster git ls-remote polling mechanism, forcing polling to require a workspace, as if you had selected the Force polling using workspace extension as well.
- Included Regions
-
Each inclusion uses java regular expression pattern matching, and must be separated by a new line. An empty list implies that everything is included.
- Excluded Regions
-
Each exclusion uses java regular expression pattern matching, and must be separated by a new line. An empty list excludes nothing.
- Excluded Messages
-
If set and Jenkins is set to poll for changes, Jenkins will ignore any revisions committed with message matched to the regular expression pattern when determining if a build needs to be triggered. This can be used to exclude commits done by the build itself from triggering another build, assuming the build server commits the change with a distinct message. You can create more complex patterns using embedded flag expressions.
When you are interested in using a job to build multiple branches, you can choose how Jenkins chooses the branches to build and the order they should be built.
This extension point in Jenkins is used by many other plugins to control the job as it builds specific commits. When you activate those plugins, you may see them installing a custom build strategy.
- Ancestry
- Maximum Age of Commit
-
The maximum age of a commit (in days) for it to be built. This uses the GIT_COMMITTER_DATE, not GIT_AUTHOR_DATE
- Commit in Ancestry
-
If an ancestor commit (SHA-1) is provided, only branches with this commit in their history will be built.
- Default
-
Build all the branches that match the branch name pattern.
- Inverse
-
Build all branches except for those which match the branch specifiers configure above. This is useful, for example, when you have jobs building your master and various release branches and you want a second job which builds all new feature branches. For example, branches which do not match these patterns without redundantly building master and the release branches again each time they change.
The git plugin can optionally merge changes from other branches into the current branch of the agent workspace. Merge extensions control the source branch for the merge and the options applied to the merge.
These options allow you to perform a merge to a particular branch before building. For example, you could specify an integration branch to be built, and to merge to master. In this scenario, on every change of integration, Jenkins will perform a merge with the master branch, and try to perform a build if the merge is successful. It then may push the merge back to the remote repository if the Git Publisher post-build action is selected.
- Name of repository
-
Name of the repository, such as origin, that contains the branch. If left blank, it’ll default to the name of the first repository configured.
- Branch to merge to
-
The name of the branch within the named repository to merge to, such as master.
- Merge strategy
-
Merge strategy selection. Choices include:
-
default
-
resolve
-
recursive
-
octopus
-
ours
-
subtree
-
recursive_theirs
-
- Fast-forward mode
-
-
--ff: fast-forward which gracefully falls back to a merge commit when required -
-ff-only: fast-forward without any fallback -
--no-ff: merge commit always, even if a fast-forward would have been allowed
-
- user.name
-
Defines the user name value which git will assign to new commits made in the workspace. If given, the environment variables
GIT_COMMITTER_NAMEandGIT_AUTHOR_NAMEare set for builds and override values from the global settings. - user.email
-
Defines the user email value which git will assign to new commits made in the workspace. If given, the environment variables
GIT_COMMITTER_EMAILandGIT_AUTHOR_EMAILare set for builds and override values from the global settings.
Unique name for this SCM. Was needed when using Git within the Multi SCM plugin. Pipeline is the robust and feature-rich way to checkout from multiple repositories in a single job.
An experiment was created many years ago that attempted to create combinations of submodules within the Jenkins job. The experiment was never available to Freestyle projects or other legacy projects like multi-configuration projects. It was visible in Pipeline, configuration as code, and JobDSL.
The implementation of the experiment has been removed. Dependabot and other configuration tools are better suited to evaluate submodule combinations.
There are no known uses of the submodule combinator and no open Jira issues reported against the submodule combinator. Those who were using submodule combinator should remain with git plugin versions prior to 4.6.0.
The submodule combinator ignores any user provided value of the following arguments to git’s checkout scm:
- doGenerateSubmoduleConfigurations
-
A boolean that is now always set to
false. Submodule configurations are no longer evaluated by the git plugin. - submoduleCfg
-
A list of submodule names and branches that is now always empty. Submodule configurations are no longer evaluated by the git plugin.
Previous Pipeline syntax looked like this:
checkout([$class: 'GitSCM',
branches: [[name: 'master']],
doGenerateSubmoduleConfigurations: false,
extensions: [],
submoduleCfg: [],
userRemoteConfigs: [[url: 'https://github.com/jenkinsci/git-plugin']]])Current Pipeline Syntax looks like this:
checkout([$class: 'GitSCM',
branches: [[name: 'master']],
extensions: [],
userRemoteConfigs: [[url: 'https://github.com/jenkinsci/git-plugin']]])The git plugin assigns values to environment variables in several contexts. Environment variables are assigned in Freestyle, Pipeline, Multibranch Pipeline, and Organization Folder projects.
- GIT_BRANCH
-
Name of branch being built including remote name, as in
origin/master - GIT_LOCAL_BRANCH
-
Name of branch being built without remote name, as in
master
- GIT_COMMIT
-
SHA-1 of the commit used in this build
- GIT_PREVIOUS_COMMIT
-
SHA-1 of the commit used in the preceding build of this project
- GIT_PREVIOUS_SUCCESSFUL_COMMIT
-
SHA-1 of the commit used in the most recent successful build of this project
- GIT_URL
-
Remote URL of the first git repository in this workspace
- GIT_URL_n
-
Remote URL of the additional git repositories in this workspace (if any)
- GIT_AUTHOR_EMAIL
-
Author e-mail address that will be used for new commits in this workspace
- GIT_AUTHOR_NAME
-
Author name that will be used for new commits in this workspace
- GIT_COMMITTER_EMAIL
-
Committer e-mail address that will be used for new commits in this workspace
- GIT_COMMITTER_NAME
-
Committer name that will be used for new commits in this workspace
Some Jenkins plugins (like email extension, build name setter, and description setter) allow parameterized references to reformat the text of supported variables. Variables that support parameterized references to reformat their text are called "token macros". The git plugin provides token macros for:
- GIT_REVISION
-
Expands to the Git SHA1 commit ID that points to the commit that was built.
- length
-
integer length of the commit ID that should be displayed.
${GIT_REVISION}might expand toa806ba7701bcfc9f784ccb7854c26f03e045c1d2, while${GIT_REVISION,length=8}would expoand toa806ba77. - GIT_BRANCH
-
Expands to the name of the branch that was built.
- all
-
boolean that expands to all branch names that point to the current commit when enabled. By default, the token expands to just one of the branch names
- fullName
-
boolean that expands to the full branch name, such as
remotes/origin/masterororigin/master. Otherwise, it expands to the short name, such asmaster.
The most common use of token macros is in Freestyle projects. Jenkins Pipeline supports a rich set of string operations so that token macros are not generally used in Pipelines.
When used with Pipeline, the token macro base values are generally assigned by the first checkout performed in a Pipeline. Subsequent checkout operations do not modify the values of the token macros in the Pipeline.
Some git plugin settings can only be controlled from command line properties set at Jenkins startup.
The default git timeout value (in minutes) can be overridden by the org.jenkinsci.plugins.gitclient.Git.timeOut property (see JENKINS-11286).
The property should be set on the controller and on all agents to have effect (see JENKINS-22547).
Command line git is the reference git implementation in the git plugin and the git client plugin.
Command line git provides the most functionality and is the most stable implementation.
Some installations may not want to install command line git and may want to disable the command line git implementation.
Administrators may disable command line git with the property org.jenkinsci.plugins.gitclient.Git.useCLI=false.
The Jenkins git plugin provides a "git publisher" as a post-build action. The git publisher can push commits or tags from the workspace of a Freestyle project to the remote repository.
The git publisher is only available for Freestyle projects. It is not available for Pipeline, Multibranch Pipeline, Organization Folder, or any other job type other than Freestyle.
The git publisher behaviors are controlled by options that can be configured as part of the Jenkins job. Options include;
- Push Only If Build Succeeds
-
Only push changes from the workspace to the remote repository if the build succeeds. If the build status is unstable, failed, or canceled, the changes from the workspace will not be pushed.
- Merge Results
-
If pre-build merging is configured through one of the merge extensions, then enabling this checkbox will push the merge to the remote repository.
- Force Push
-
Git refuses to replace a remote commit with a different commit. This prevents accidental overwrite of new commits on the remote repository. However, there may be times when overwriting commits on the remote repository is acceptable and even desired. If the commits from the local workspace should overwrite commits on the remote repository, enable this option. It will request that the remote repository destroy history and replace it with history from the workspace.
The git publisher can push tags from the workspace to the remote repository. Options in this section will allow the plugin to create a new tag. Options will also allow the plugin to update an existing tag, though the git documentation strongly advises against updating tags.
- Tag to push
-
Name of the tag to be pushed from the local workspace to the remote repository. The name may include Jenkins environment variables or may be a fixed string. For example, the tag to push might be
$BUILD_TAG,my-tag-$BUILD_NUMBER,build-$BUILD_NUMBER-from-$NODE_NAME, ora-very-specific-string-that-will-be-used-once. - Tag message
-
If the option is selected to create a tag or update a tag, then this message will be associated with the tag that is created. The message will expand references to Jenkins environment variables. For example, the message
Build $BUILD_NUMBER tagged on $NODE_NAMEwill use the messageBuild 1 tagged on special-agentif build 1 of the job runs on an agent named 'special-agent'. - Create new tag
-
Create a new tag in the workspace. The git publisher will fail the job if the tag already exists.
- Update new tag
-
Modify existing tag in the workspace so that it points to the most recent commit. Many git repository hosting services will reject attempts to push a tag which has been modified to point to a different commit than its original commit. Refer to force push for an option which may force the remote repository to accept a modified tag. The git documentation strongly advises against updating tags.
- Tag remote name
-
Git uses the 'remote name' as a short string replacement for the full URL of the remote repository. This option defines which remote should receive the push. This is typically
origin, though it could be any one of the remote names defined when the plugin performs the checkout.
The git publisher can push branches from the workspace to the remote repository. Options in this section will allow the plugin to push the contents of a local branch to the remote repository.
- Branch to push
-
The name of the remote branch that will receive the latest commits from the agent workspace. This is usually the same branch that was used for the checkout
- Target remote name
-
The short name of the remote that will receive the latest commits from the agent workspace. Usually this is
origin. It needs to be a short name that is defined in the agent workspace, either through the initial checkout or through later configuration. - Rebase before push
-
Some Jenkins jobs may be blocked from pushing changes to the remote repository because the remote repository has received new commits since the start of the job. This may happen with projects that receive many commits or with projects that have long running jobs. The
Rebase before pushoption fetches the most recent commits from the remote repository, applies local changes over the most recent commits, then pushes the result. The plugin usesgit rebaseto apply the local changes over the most recent remote changes.Because
Rebase before pushis modifying the commits in the agent workspace after the job has completed, it is creating a configuration of commits that has not been evaluated by any Jenkins job. The commits in the local workspace have been evaluated by the job. The most recent commits from the remote repository have not been evaluated by the job. Users may find that the risk of pushing an untested configuration is less than the risk of delaying the visibility of the changes which have been evaluated by the job.
A single reference repository may contain commits from multiple repositories.
For example, if a repository named parent includes references to submodules child-1 and child-2, a reference repository could be created to cache commits from all three repositories using the commands:
$ mkdir multirepository-cache.git $ cd multirepository-cache.git $ git init --bare $ git remote add parent https://github.com/jenkinsci/git-plugin $ git remote add child-1 https://github.com/jenkinsci/git-client-plugin $ git remote add child-2 https://github.com/jenkinsci/platformlabeler-plugin $ git fetch --all
Those commands create a single bare repository with the current commits from all three repositories. If that reference repository is used in the advanced clone options clone reference repository, it will reduce data transfer and disc use for the parent repository. If that reference repository is used in the submodule options clone reference repository, it will reduce data transfer and disc use for the submodule repositories.
Report issues and enhancements in the Jenkins issue tracker.
Refer to contributing to the plugin for contribution guidelines. Refer to plugin development priorities for the prioritized list of development topics.
The git plugin has an issue (JENKINS-19022) that sometimes causes excessive memory use and disc use in the build history of a job. The problem occurs because in some cases the git plugin copies the git build data from previous builds to the most recent build, even though the git build data from the previous build is not used in the most recent build. The issue can be especially challenging when a job retains a very large number of historical builds or when a job builds a wide range of commits during its history.
Multiple attempts to resolve the core issue without breaking compatibility have been unsuccessful. A workaround is provided below that will remove the git build data from the build records. The workaround is a system groovy script that needs to be run from the Jenkins Administrator’s Script Console (as in https://jenkins.example.com/script ). Administrator permission is required to run system groovy scripts.
This script removes the static list of BuildsByBranch that is stored for each build by the Git Plugin.
import hudson.matrix.*
import hudson.model.*
hudsonInstance = hudson.model.Hudson.instance
jobNames = hudsonInstance.getJobNames()
allItems = []
for (name in jobNames) {
allItems += hudsonInstance.getItemByFullName(name)
}
// Iterate over all jobs and find the ones that have a hudson.plugins.git.util.BuildData
// as an action.
//
// We then clean it by removing the useless array action.buildsByBranchName
//
for (job in allItems) {
println("job: " + job.name);
def counter = 0;
for (build in job.getBuilds()) {
// It is possible for a build to have multiple BuildData actions
// since we can use the Mulitple SCM plugin.
def gitActions = build.getActions(hudson.plugins.git.util.BuildData.class)
if (gitActions != null) {
for (action in gitActions) {
action.buildsByBranchName = new HashMap<String, Build>();
hudson.plugins.git.Revision r = action.getLastBuiltRevision();
if (r != null) {
for (branch in r.getBranches()) {
action.buildsByBranchName.put(branch.getName(), action.lastBuild)
}
}
build.actions.remove(action)
build.actions.add(action)
build.save();
counter++;
}
}
if (job instanceof MatrixProject) {
def runcounter = 0;
for (run in build.getRuns()) {
gitActions = run.getActions(hudson.plugins.git.util.BuildData.class)
if (gitActions != null) {
for (action in gitActions) {
action.buildsByBranchName = new HashMap<String, Build>();
hudson.plugins.git.Revision r = action.getLastBuiltRevision();
if (r != null) {
for (branch in r.getBranches()) {
action.buildsByBranchName.put(branch.getName(), action.lastBuild)
}
}
run.actions.remove(action)
run.actions.add(action)
run.save();
runcounter++;
}
}
}
if (runcounter > 0) {
println(" -->> cleaned: " + runcounter + " runs");
}
}
}
if (counter > 0) {
println("-- cleaned: " + counter + " builds");
}
}
