Notes: Refactor floating board measurement

[Mamaduka]

What?

Fixes #83508.
Follow-up to #79877 (review thread).

Rewrites createBoardStore and useFloatingBoard so all DOM reads happen in the store's ResizeObserver callback, React reads a value-compared snapshot through useSyncExternalStore, and note positions are derived during render. Moves the inline note helpers from hooks.js to utils.js.

Additional fixes:

• Threads follow a noted block moved up or down, including during the move animation. Before, they kept their old order until the selection changed.
• Threads stay aligned when content above the canvas moves it (editor notices, device preview).
• A remount of the floating sidebar no longer paints one frame with every thread at the same spot.
• A note inside a closed Details block aligns with the Details block instead of floating over the next block.
• Threads ease into place on selection change, unless the user prefers reduced motion.
• A thread without an anchor (block hidden with Block Visibility) stays hidden instead of dropping to the top of the panel. Re-selecting a hidden block loses its note position #73565 stays open.

Note

I know it's a sizable change, but it's mostly internal cleanup + bug fixes. Floating notes behavior should be the same, if not better.

Why?

The extra requestAnimationFrame after the ResizeObserver caused two paints per change and hid resize loops. The block move animation offsets moved blocks with a transform, which doesn't resize anything, so the only measurement read their old positions.

How?

The observer exists only while the board has subscribers, and requestMeasure() re-observes the root to get another pass before the next paint, on register and on threads changes. Anchors are stored in canvas content-space, so scrolling never re-renders; --canvas-scroll and --canvas-offset CSS variables move the threads instead. A MutationObserver on style attributes under the root re-measures while blocks animate.

Testing Instructions

1. Open a post and switch to the floating notes sidebar.
2. Add two paragraphs, "Alpha" and "Bravo", and add a note to each.
3. Select "Bravo" and click Move up. The threads swap with the blocks and follow them during the animation.
4. Move the block up and down a few times. The thread order always matches the block order.
5. Scroll the canvas and add a reply to a thread. Threads stay aligned with their blocks, and the thread below is pushed down.
6. Select the other paragraph. Threads ease into their new spots.
7. Switch the preview to Tablet. Threads stay aligned with their blocks.

Closed Details block

1. Add a Details block with a summary and a paragraph inside it.
2. Add a note to the paragraph. The thread aligns with the paragraph.
3. Click the summary to close the Details. The thread aligns with the summary.
4. Click the summary again. The thread aligns with the paragraph.

Automated: collab-sidebar unit tests (146) pass. block-notes, block-notes-floating and collaboration-notes e2e on Chromium: 67 passed, 1 skipped (existing fixme).

Testing Instructions for Keyboard

Same as above.

Screencast

Before

CleanShot.2026-09-24.at.13.25.18.mp4

After

CleanShot.2026-09-24.at.13.23.19.mp4

Use of AI Tools

Assisted by Claude.

[Mamaduka]

Please let me know if you can think of additional edge cases for floating notes. I would like to improve our e2e test coverage for it.

[github-actions]

The following accounts have interacted with this PR and/or linked issues. I will continue to update these lists as activity occurs. You can also manually ask me to refresh this list by adding the props-bot label.

If you're merging code through a pull request on GitHub, copy and paste the following into the bottom of the merge commit message.

Co-authored-by: Mamaduka <mamaduka@git.wordpress.org>
Co-authored-by: jasmussen <joen@git.wordpress.org>
Co-authored-by: t-hamano <wildworks@git.wordpress.org>
Co-authored-by: adamsilverstein <adamsilverstein@git.wordpress.org>
Co-authored-by: i-am-chitti <iamchitti@git.wordpress.org>

To understand the WordPress project's expectations around crediting contributors, please review the Contributor Attribution page in the Core Handbook.

[github-actions]

🤖 PR meta 🤖

📦 Bundle size

Size Change: +730 B (+0.01%)

Total Size: 8.24 MB

📦 View Changed

Filename	Size	Change
build/scripts/editor/index.min.js	614 kB	+409 B (+0.07%)
build/styles/editor/style-rtl.css	31.8 kB	+83 B (+0.26%)
build/styles/editor/style-rtl.min.css	27.1 kB	+79 B (+0.29%)
build/styles/editor/style.css	31.8 kB	+82 B (+0.26%)
build/styles/editor/style.min.css	27.1 kB	+77 B (+0.29%)

_{e8c9374 Run}

⚡ Performance

Show the results

Client side metrics exclude the server response time.

front-end-block-theme

Metric	cee60be	trunk	% Change
timeToFirstByte	62 ms +7.1% -7.02%	58.05 ms +3.88% -2.58%	6.8%
largestContentfulPaint	100 ms +8% -6%	94 ms +10.64% -2.13%	6.38%
lcpMinusTtfb	37.1 ms +19.14% -7.14%	35.35 ms +19.8% -4.38%	4.95%
wpBeforeTemplate	32.34 ms +8.13% -11.78%	28.4 ms +8.7% -1.62%	13.87%
wpTemplate	25.65 ms +6.98% -2.73%	25.32 ms +3.32% -2.29%	1.3%
wpTotal	58.11 ms +6.11% -7.12%	54.4 ms +4.06% -2.67%	6.82%
wpMemoryUsage	7.61 MB +0% -0%	7.57 MB +0% -0%	0.51%
wpDbQueries	17 +0% -0%	17 +0% -0%	0%

front-end-classic-theme

Metric	cee60be	trunk	% Change
timeToFirstByte	44.2 ms +8.71% -2.83%	43.95 ms +5.23% -2.62%	0.57%
largestContentfulPaint	96 ms +2.08% -4.17%	96 ms +0% -4.17%	0%
lcpMinusTtfb	50.2 ms +2.89% -3.19%	50.1 ms +5.79% -2.89%	0.2%
wpBeforeTemplate	26.79 ms +8.51% -1.75%	26.74 ms +2.73% -2.06%	0.19%
wpTemplate	14.13 ms +3.61% -2.55%	13.99 ms +4.15% -1.36%	1%
wpTotal	41.21 ms +9.12% -2.55%	40.85 ms +5.9% -2.01%	0.88%
wpMemoryUsage	6.09 MB +0% -0%	6.05 MB +0% -0%	0.59%
wpDbQueries	10 +0% -0%	10 +0% -0%	0%

media-processing

Metric	cee60be	trunk	% Change
mediaProcessingJpeg	407.31 ms +1.32% -1.02%	399.9 ms +2.4% -0.24%	1.85%
mediaProcessingAvif	6117.61 ms +0.43% -0.04%	6072.74 ms +0.38% -0.09%	0.74%
mediaProcessingJpegToAvif	4243.83 ms +0.6% -0.34%	4206.93 ms +0.27% -0.3%	0.88%

media-upload

Metric	cee60be	trunk	% Change
jpegUploadProcessing	1435.36 ms +36.67% -1.68%	1433.6 ms +0.92% -0.46%	0.12%
pngUploadProcessing	202.47 ms +14.26% -15.17%	236.38 ms +15.66% -22.43%	-14.35%
largeJpegUploadProcessing	1415.52 ms +0.87% -1.04%	1425.59 ms +0.57% -0.37%	-0.71%
multipleImageUploadProcessing	1572.35 ms +2.99% -0.38%	1596.27 ms +32.34% -0.77%	-1.5%

post-editor

Metric	cee60be	trunk	% Change
serverResponse	250.69 ms +5.99% -6.67%	238.02 ms +7.71% -5.73%	5.32%
firstPaint	129.77 ms +27.78% -7.41%	182.61 ms +43.78% -25.27%	-28.94%
domContentLoaded	645.83 ms +1.94% -1.69%	623.85 ms +1.35% -4.52%	3.52%
loaded	646.79 ms +1.93% -1.72%	624.96 ms +1.3% -4.56%	3.49%
firstContentfulPaint	291.85 ms +0.7% -5.24%	280.25 ms +3.56% -6.31%	4.14%
firstBlock	1861.77 ms +2.39% -0.3%	1848.71 ms +1.83% -1.44%	0.71%
type	12.02 ms +2.91% -1.08%	11.63 ms +15.74% -0.95%	3.35%
typeWithoutInspector	11.98 ms +6.18% -4.26%	12.22 ms +3.44% -4.17%	-1.96%
typeWithTopToolbar	15.2 ms +4.28% -2.96%	15.63 ms +1.47% -2.5%	-2.75%
typeContainer	0.64 ms +32.81% -37.5%	0.62 ms +35.48% -38.71%	3.23%
focus	7.96 ms +14.57% -3.64%	7.58 ms +20.45% -2.64%	5.01%
firstFocus	16.64 ms +0% -0%	17.22 ms +0% -0%	-3.37%
selectAll	847.59 ms +1.5% -4.59%	804.74 ms +5.77% -4.07%	5.32%
listViewOpen	35.16 ms +7.91% -7.31%	35.82 ms +13.26% -5.5%	-1.84%
inserterOpen	14.96 ms +17.25% -7.29%	15.09 ms +11.53% -10.47%	-0.86%
inserterHover	1.52 ms +3.29% -15.13%	1.53 ms +9.15% -11.11%	-0.65%
inserterSearch	5.8 ms +1.21% -2.59%	5.93 ms +6.91% -7.42%	-2.19%
loadPatterns	399.74 ms +1.79% -3.15%	385.89 ms +6.14% -2.63%	3.59%
wpTotal	244.03 ms +6.05% -6.95%	231.24 ms +7.98% -5.78%	5.53%
wpMemoryUsage	13.14 MB +0% -0%	13.11 MB +0% -0%	0.28%
wpDbQueries	54 +0% -0%	54 +0% -0%	0%

site-editor

Metric	cee60be	trunk	% Change
serverResponse	324.66 ms +3.86% -3.63%	341.89 ms +1.93% -7.82%	-5.04%
firstPaint	197.8 ms +18.62% -12.66%	220 ms +22.43% -8.62%	-10.09%
domContentLoaded	877.38 ms +1.29% -1.33%	926.59 ms +2.64% -2.86%	-5.31%
loaded	878.42 ms +1.29% -1.34%	927.77 ms +2.62% -2.87%	-5.32%
firstContentfulPaint	358.72 ms +1.66% -20.35%	385.82 ms +1.63% -4.65%	-7.02%
firstBlock	3156.36 ms +0.3% -0.88%	3306.9 ms +0.62% -1.35%	-4.55%
type	16.38 ms +5.56% -1.89%	17.8 ms +4.66% -4.38%	-7.98%
navigate	110.15 ms +5.42% -10.86%	137.12 ms +4.24% -16.56%	-19.67%
loadPatterns	1138.93 ms +21.68% -5.23%	1136.99 ms +5.11% -15.03%	0.17%
loadPages	1103.59 ms +3% -1.01%	1140.02 ms +2.21% -0.32%	-3.2%
wpTotal	316.25 ms +3.93% -3.75%	333.51 ms +1.92% -8.1%	-5.18%
wpMemoryUsage	12.11 MB +0% -0%	12.09 MB +0% -0%	0.13%
wpDbQueries	44 +0% -2.27%	43.5 +1.15% -1.15%	1.15%

_{e8c9374 Run}

[Mamaduka]

I've been doing some stress testing with Claude, and I think I managed to fix all the paper cuts we could find. Updated the PR summary to include a list of all fixes and improvements.

[adamsilverstein]

I've also been doing some testing and will post the results soon. manual testing seemed fine, but Claude found a few edge cases worth reviewing.

[adamsilverstein]

Nice work on the follow-up fixes. I ran a Playwright stress pass against 1ee2b26 and most of what came up is already covered, a few things left below. The first two also happen on trunk, so fine as follow-ups if you'd rather keep this PR scoped.

Claude ran the edge cases side by side with trunk, here is what is left:

Compared against the trunk merge-base, with about 20 scenarios measuring each floating thread's offset from its anchor. Now aligned on this PR: moving a noted block with no selection change, move + undo/redo, delete + undo, inserting a block above a transformed block, editor notices above the canvas, and Tablet preview. No console errors or ResizeObserver loop warnings, and scrolling does not trigger a re-measure.

1. A growing post title leaves threads behind (also on trunk). Typing a title long enough to wrap onto more lines scrolls the canvas, and every thread ends up ~740px above its block, so the top thread scrolls out of view. The title sits outside .is-root-container, so the root moves without resizing and nothing re-measures. Observing the scroll container's content (or the title wrapper) instead of only the root would catch it.

2. Duplicating a noted block (also on trunk). The copy keeps metadata.noteId, so two blocks share note 199. The sidebar then renders two threads with the same DOM id note-thread-199, stacked on top of each other ~180px below both blocks. The board is keyed by note id, so the two threads share one registration. This is probably more of a "should duplicate copy the note at all" question than a measurement bug.

3. Cost of the style MutationObserver during move animations (new in this PR). Each animation frame re-measures every anchor. With 20 notes, six animated Move down presses took ~0.60s of script time and 185 layouts on this PR, vs ~0.20s and 40 layouts on trunk. With 3 notes, a single toolbar move went from 36ms to 56ms. Not a visible stutter at these sizes, but it grows with note count. Coalescing the mutation callbacks per frame, or only re-measuring while a transform is active, might keep the benefit for less work.

[adamsilverstein]

Duplicating a noted block (also on trunk).

I feel like we noticed this before and its related to a deeper issue being worked on elsewhere. Do we have a notes specific issue for this? Is it worth having one @Mamaduka ?

[adamsilverstein]

A growing post title leaves threads behind (also on trunk)

I hadn't noticed this before (but verified it manually), do you want to address it in this PR @Mamaduka? Otherwise I will open a separate issue.

[Mamaduka]

A growing post title leaves threads behind.

Confirmed as well. This looks like an issue worth handling, since it's part of the position/layout logic.

Duplicating a noted block

This is known issue #71544 / #29693 and not necessarily a layouting problem. We need to figure out how to handle rendering a note that belongs to multiple blocks. Related: #73416. Let's handle it in a follow-up.

Cost of the style MutationObserver during move animations

I also flagged something similar when fixing the moving blocks problem here. Will double-check.

[Mamaduka]

@adamsilverstein, I fixed 1 and 3. Let's handle 2 in a follow-up.

[t-hamano]

Currently, opacity: 0 is applied to all notes without block anchors, as well as the new note form. As a result, even when a note is visually hidden because its linked block is unselected, it can still receive focus. Should we apply the inert attribute to these notes?

[Mamaduka]

Let's try to resolve the hidden block notes as part of #73565. As the inline comment states, using opacity is intentional; the user might trigger note focus before the position settles, and focus might be missed. Using inert will cause the same problem, similar to the visibility property.

[t-hamano]

I don't see any other issues with this PR. Let's merge it and address the remaining concerns in follow-up tasks 👍

[Mamaduka]

Thanks for the feedback, everyone!
