feat(relay): multi-platform-per-agent — list identity, N-hello, per-frame egress (Phase 1.5)

[benbarclay]

Multi-platform-per-agent — the gateway half (Phase 1.5, Shape A)

One hosted agent now fronts a set of platforms (e.g. Discord and Telegram) over a single relay WebSocket, instead of being pinned to one. This is the hermes-agent half of the cross-repo cut-over; it pairs with the connector's per-frame egress (gateway-gateway #75, already merged) and the NAS deploy-config stamp (nous-account-service feat/relay-multiplatform-stamp).

What changed (gateway/relay/)

• relay_platform_identities() parses the env-scoped deploy config into the ordered (platform, bot_id) set:
  • GATEWAY_RELAY_PLATFORMS — comma-sep list (e.g. discord,telegram)
  • GATEWAY_RELAY_BOT_IDS — JSON keyed map {"discord":{"botId":"…"},"telegram":{"botId":"…","username":"…"}}
  • Cut over from the scalar GATEWAY_RELAY_PLATFORM/_BOT_ID — no fallback path retained (per the design decision). A malformed map degrades to empty bot ids (boot never crashes).
• self_provision_relay() loops one /relay/provision POST per platform under one gatewayId + one secret, partial-failure-tolerant (one platform's bad config doesn't sink the rest).
• WebSocketRelayTransport holds the identity set, sends one hello per identity (the connector accumulates them into its advertised set), and stamps the per-frame OutboundFrame.platform + its matching advertised botId on every outbound.
• RelayAdapter remembers each chat's underlying source.platform on inbound (mirroring the existing guild/DM scope-capture) and tags the reply's egress platform — so a reply routes back through the right sender.
• send_relay_policy() declares one relevance policy per fronted platform (the connector keys policy by (tenant, platform, instanceId)).

Back-compat

A single-platform deploy passes a 1-element list and emits no per-frame tag → the connector falls back to the session-default platform → the wire shape is byte-identical to before.

Verification

• ruff clean, tsc-equivalent (pyright) clean on changed files.
• Relay unit suite: 221 pass / 1 skip (211 baseline + 10 new multi-platform tests: list/map parse, provision-loop multi + partial-failure, per-frame egress tag).
• All 15 cross-repo E2E drivers green against the connector at origin/main (with fix(whatsapp): multi-user session isolation and bridge message handling #75) — proving the N-hello + per-frame-egress wire interop on real sockets, plus the single-platform back-compat path.

⚠️ Atomic cut-over — no scalar fallback. This must land together with the NAS stamp PR and the prod/staging env-var migration so a recreated container never gets a half-old/half-new env. See the relay-platform-parity spec (D-Q1.5c).

Infographic

[github-actions]

🔎 Lint report: feat/relay-multiplatform-agent vs origin/main

ruff

Total: 0 on HEAD, 0 on base (➖ 0)

🆕 New issues: none

✅ Fixed issues: none

Unchanged: 0 pre-existing issues carried over.

ty (type checker)

Total: 11365 on HEAD, 11364 on base (🆕 +1)

🆕 New issues (3):

Rule	Count
unresolved-import	1
invalid-argument-type	1
invalid-assignment	1

First entries

tests/gateway/relay/test_relay_multiplatform.py:19: [unresolved-import] unresolved-import: Cannot resolve imported module `pytest`
tests/gateway/relay/test_relay_multiplatform.py:226: [invalid-argument-type] invalid-argument-type: Argument to `RelayAdapter.__init__` is incorrect: Expected `RelayTransport | None`, found `StubConnector`
tests/run_agent/test_credits_notices_toggle.py:76: [invalid-assignment] invalid-assignment: Object of type `None` is not assignable to attribute `_credits_session_start_micros` of type `int`

✅ Fixed issues (2):

Rule	Count
unresolved-attribute	2

First entries

tests/run_agent/test_credits_notices_toggle.py:76: [unresolved-attribute] unresolved-attribute: Unresolved attribute `_credits_session_start_micros` on type `AIAgent`
run_agent.py:2989: [unresolved-attribute] unresolved-attribute: Object of type `Self@get_credits_spent_micros` has no attribute `_credits_session_start_micros`

Unchanged: 5992 pre-existing issues carried over.

Diagnostics are surfaced as warnings — this check never fails the build.

[tonydwb]

Code Review Summary

Verdict: Approved

Phase 1.5 multi-platform-per-agent relay feature. Adds the ability for one gateway to front N platforms on a single WS connection, with per-frame egress tagging.

Looks Good

• relay_platform_identities() cleanly parses GATEWAY_RELAY_PLATFORMS + GATEWAY_RELAY_BOT_IDS with graceful degradation for malformed JSON
• self_provision_relay() loop is partial-failure-tolerant: one platform failing does not block others
• Per-frame egress tagging via platform kwarg on send_outbound/send_follow_up is backward-compatible (single-platform gateways emit the same frame shape as before)
• _bot_id_for() correctly resolves the matching botId for each platform's advertised set
• Multi-hello handshake (one hello per identity) is clean
• Comprehensive test suite: identity parsing, provision loop, partial failure, adapter egress tagging, untagged fallback
• Transport stub updated correctly for tests

---

Reviewed by Hermes Agent
