VR-Dialogues: Navigating Conversations with Virtual Agents

By Alen Jo, Evan Olson, Hrishikesh Srirangam, Aastha Sharma, Yadiel Valentin Rios, Abbas Khawaja

Introduction

Virtual Reality (VR) has significantly changed how users engage with digital spaces. However, many existing systems focus on one-on-one conversations, failing to address the complexity of multi-agent interactions (Josyula et al., 2024). We introduce VR Dialogues, an immersive VR conversational system that generates realistic, dynamic interactions between a user and two virtual agents. By integrating an LLM, lifelike avatars, and immersive environments, VR Dialogues enhances the virtual reality experience, offering a more collaborative and synergistic form of interaction. This system brings a new level of immersion and interactivity to VR environments, demonstrating the potential for scalable, multi-agent conversations.

Architecture

Figure 1. Architecture of VR Dialogues

The design goal embodies user comfort and control with a seamless user experience and a robust backend. This comfort is what allows the user to enjoy their experience and stimulates more intrigue. To begin, the user enters the game scene facing the agents. The agents will greet the user and start the conversation (e.g., Figure 1). A Speech-To-Text model will process the user’s responses, which feeds the text into an OpenAI Large Language Model (LLM) to generate the agent response. The LLM has multiple custom prompts that allow users to enjoy multiple personalities. In conjunction with these responses, the animations employ advanced lip-syncing techniques to make these agents more lifelike.

More on the backend: The flow chart indicates that the backend consists of a Python and C# component. The Python backend first handles the microphone input to detect speech by removing ambient noise, adjusting noise gain, and clipping audio after detecting silence. Then, the recorded audio goes through a transcription layer that converts the audio into proper speech. OpenAI's LLM is the intermediary that connects the speech-to-text and text-to-speech modules by generating the appropriate response and saving it as plaintext. This plaintext then goes through Google's TTS API, which spits out an audio file. Unity's Audio Engine picks up this new audio file through file synchronization of specific characters between the Python and Unity intermediates that then play the audio file in the game scene.

Components

Response Generation: We use GPT-3.5 to generate contextually relevant responses based on user input. In our VR environment, the avatars "Kirtana" and "Ezio" engage in a three-way dialogue with the user, managed by a Python script that syncs with Unity for real-time interaction (e.g., Figure 2). The avatars also have interchangeable personality traits for an adaptive and engaging experience.

Response generation pipeline

1. Microphone Input

audio_data = sd.rec(int(duration * 44100), samplerate=44100, channels=1, dtype='int16')
sd.wait()  # Wait until the recording is finished
with wave.open(filename, 'wb') as wf:
    wf.setnchannels(1)  # Mono
    wf.setsampwidth(2)  # 16 bits
    wf.setframerate(44100)
    wf.writeframes(audio_data.tobytes())

Take in a sound device and instantiate input properties, such as the sample rate at 44100 Hz, mono-channel, and 16-bit audio blocks. 44100 Hz comes from a fantastic theorem (google the Nyquist-Shannon sampling principle) that captures frequencies up to 22 kHz (above the upper limit for human hearing). Therefore, to add cushioning for human hearing, double it. A mono-channel configuration allows us to make the audio file small for more straightforward encoding and decoding. Finally, 16-bit is lossless or allows for leeway of better speech recognition and toying around with loudness in certain audio blocks.

We then use a context manager to encode <--> decode the microphone audio and write as bytes into a WAVE file. WAVE files are made purely using raw bytes, which means they have pure sound quality (excellent for transcription).

2. Speech-To-Text Transcriber

recognizer = sr.Recognizer()
with sr.Microphone() as source:
    print("Listening...")
    audio = recognizer.listen(source, timeout=2)

Instantiate a Speech Recognition object that includes the microphone array to take in audio input continuously until the recognition model detects speech from py recognizer.recognize_google(audio). Since speech recognition is susceptible to errors, there are also three defined Exception classes:

except sr.UnknownValueError:
    print("Sorry, I could not understand the audio.")
    return ""
except sr.RequestError as e:
    print(f"Could not request results from Google Speech Recognition service; {e}")
    return ""
except sr.WaitTimeoutError:
    return ""

UnknownValueError - failure in transcribing the user audio, which this error is harmless and warrants no response.
RequestError - failure in fetching the transcription service through its internal API
WaitTimeOutError - reached the silence detection threshold that prematurely clips the microphone input

3. OpenAI LLM Intermediary

# Append user input to both conversations
conversation1.append({'role': 'user', 'content': user_input})
conversation2.append({'role': 'user', 'content': user_input})

# Randomly select an agent to respond
agentSelected = random.randint(1, 2)

# Get the appropriate response from OpenAI
response = (gpt3(conversation1) if agentSelected == 1 else gpt3(conversation2))

Once the speech-to-text extracts the appropriate transcription, feed it into a list of JSON objects fed into the OpenAI API. To prevent monotonicity in the agent, randomize the agent to give the user comfort in speaking to different people rather than a single person. Check the following for how we invoke the OpenAI LLM:

response = openai.ChatCompletion.create(
    model=model,
    messages=messages,
    temperature=temperature,
    max_tokens=max_tokens,
    frequency_penalty=frequency_penalty,
    presence_penalty=presence_penalty
)
response_text = response['choices'][0]['message']['content'].strip()
return response_text

To get an appropriate response from OpenAI's ChatGPT model, we need to invoke a ChatCompletion function that allows for selecting the model (i.e., GPT 3.5), the messages (List of JSON objects), temperature (model's creativity), max_tokens (how many characters allowed for response), frequency penalty (prevents repeating the exact phrases or words), and presence penalty (be more diverse in the conversation).

All of these parameters make agent responses genuine and realistic, and the successful generation returns as plaintext. Of course, there will be errors encountered (like invalid API requests), which are handled like so.

except Exception as e:
    print(f"Error calling OpenAI API: {e}")
    return "I'm having trouble responding right now."

4. Text-to-Speech Transcriber For Kitana:

text_to_wav("en-US-Standard-H", response, "girlAudio")  # Female voice for Kitana
conversation1.append({'role': 'system', 'content': response})
conversation2.append({'role': 'user', 'content': f'Kitana said "{response}"'})
with open("sync.txt", "a") as sync_file:
    sync_file.write("a1\n")

With Kitana, we invoke a text_to_wav function that takes the standard US English locale, the response, and then the audio name. The response manipulates the conversation lists that pass as JSON objects for the system (OpenAI's LLM) and user (agent). Finally, write a sync file that tells the TTS module it's ready to play the audio!

text_to_wav("en-US-Standard-J", response, "boyAudio")  # Male voice for Ezio
conversation1.append({'role': 'user', 'content': f'Ezio said "{response}"'})
conversation2.append({'role': 'system', 'content': response})
with open("sync.txt", "a") as sync_file:
    sync_file.write("a2\n")

However, notice the Ezio code block. The difference derives from which role goes first. In Kitana, it's the LLM response and then the agent response. However, Ezio is the agent response, followed by the LLM response. This design choice allows for a two-way conversation (alludes to the next section) between the two agents and the user, creating a social ambiance!

5. Two-way conversation between the agents

agent_count = 0
while agent_count < 3:
    agentSelected = 2 if agentSelected == 1 else 1  # Switch agent
    response = (gpt3(conversation1) if agentSelected == 1 else gpt3(conversation2))
    tts(response, agentSelected)
    agent_count += 1

Remember how we want to avoid monotonicity (or redundancy rather) for one agent speaking the entire time? This allows variance in which the agent speaks first and gives that social creativity! It's not enough to personalize the LLM models to provide human-like responses; we need to "physically" mimic the social interaction seen routinely.

Avatars and Animations: Our agents’ avatars were designed with Ready Player Me and animated using Mixamo and custom Blender animations (e.g., Figure 3 & 4). This approach enhances avatar liveliness, promoting user social presence (Qazi & Qazi, 2023). Animations and expressions are dynamically adjusted based on speech sentiment, enabling natural interactions. Each agent (Ezio and Kirtana) has 8 avatars each. Upon colliding with the respective clothing item in the wardrobe corresponding to some avatar, their speech prompt will be adjusted to a new personality and the skin child that matches the clothing will be set to active while the previously active skin child will be set to inactive. With this active-inactive infrastructure in each avatar's children, many avatars can be present in the scene with all their components without any conflict.

Figure 2. Agents Talking

Figure 3. Kirtana

Figure 4. Ezio Clapping

Environment: To suit various preferences, we included a park environment in addition to a more enclosed office environment (Riches et al., 2019). We implemented an elevator system to seamlessly transition between these environments (e.g., Figure 5). This is accomplished with buttons that are activated with the user’s hands. When a button is pressed, the door closes, and the elevator is teleported to the corresponding environment, along with the user. Then, the door reopens, revealing the new environment. This method of transporting the user hides any jarring transitions from the user. Additionally, we added interactable elements to the scenes to enhance the user's sense of presence within the scene. For example, the items on the desk in the office can be moved, shattered, or toggled. The park scene contains a fountain that summons a wardrobe from above when the user puts their hand in the water. To add further detail to the park scene, we added several people jogging around. This is acheived using a script on each background person. When the scene starts, a NavMeshAgent and Animator are initialized for the person, and a coroutine is started.

void Start()
{
    agent = GetComponent<NavMeshAgent>();
    animator = GetComponentInChildren<Animator>();
    StartCoroutine(SetNewDestination());
}

Inside the coroutine, a random position near the person is selected, and a ray is shot towards the ground from here. This is the target position where the person will run to next.

IEnumerator SetNewDestination()
{
    while (true)
    {
        RaycastHit hit;
        if (Physics.Raycast(transform.position + new Vector3(Random.Range(-15, 15), 50, Random.Range(-15, 15)), Vector3.down, out hit))
              target = hit.point;
    }
...

Then, if the person is already at its previous target or 10 seconds have passed, the person's NavMeshAgent will set the new target as its destination, and the person will start to run towards it. This process is repeated every 4-6 seconds.

if (agent.remainingDistance < 0.2f || timer > 10)
{
    agent.SetDestination(target);
    timer = 0;
}
yield return new WaitForSeconds(Random.Range(4f, 6f));

To determine the animation of the person, the person's speed is fed into its Animator every frame, and if it exceeds a certain threshold, the person will use a running animation. Otherwise, it will use an idle animation.

private void Update()
{
    if (animator != null)
        animator.SetFloat("MoveSpeed", (transform.position - previousPosition).magnitude / Time.deltaTime);
    timer += Time.deltaTime;
    previousPosition = transform.position;
}

Figure 5. Elevator

Figure 6. Wardrobe

Wardrobe: To allow users to customize the agents, we designed a system to alter the appearance and behavior of each agent (e.g., Figure 6). Pressing either the fountain in the park scene or the button on the desk in the office scene moves objects in the scene out of the way, and the agents stop speaking. The users then grabs one of the eight outfits and drags it towards either agent to change their personality as well as their speaking behavior. This happens through a numeric system. Each outfit and agent appearance has a number component that will be used to match both components together. When the outfit touches an agent, the agent appearance currently selected will be set unactive and the one with the number component matching the outfit touching it will be set active. The text prompt will change based on its index in the array it's contained in. This is the main loop that is triggered when an outfit touches an agent:

void ChangeSkin()
{
    if (currentNum != 0)
    {
        foreach (Transform child in transform)
        {
            if (child.gameObject.GetComponent<AvatarComponent>().num == currentNum)
            {
                child.gameObject.SetActive(true);
                currentNum = child.gameObject.GetComponent<AvatarComponent>().num;
                File.WriteAllText(AssetDatabase.GetAssetPath(chatPrompt), prompts[currentNum - 1]);
                SetOthersInactive(currentNum);
                if (pythonProcess != null && !pythonProcess.HasExited)
                {
                    pythonProcess.Kill();
                    pythonProcess.Dispose();
                }
                break;
            }
        }

    }
}

Then, the outfit returns to its original position on the wardrobe. The wardrobe can be sent away by pressing the button on it and the scene will revert to how it was before.

private void Update()
{
    if (moveToPosition2)
    {
        for (int i = 0; i < propDatas.Length; i++)
            propDatas[i].prop.position = Vector3.Lerp(propDatas[i].prop.position, propDatas[i].position2.position, propDatas[i].speed2);
    }
    else
    {
        for (int i = 0; i < propDatas.Length; i++)
            propDatas[i].prop.position = Vector3.Lerp(propDatas[i].prop.position, propDatas[i].position1.position, propDatas[i].speed1);
    }
}

Results and Analysis

Figure 7. Reported Social Presence Values of Participants

Detailed Metric Analysis

1. Inclusion

Summary: Users rated their sense of inclusion in conversations with virtual agents highly.
Statistical Breakdown:

• Median: 6.0 (The middle 50% of responses clustered around this high score.)
• Mean: ~6.0 (In line with the median, indicating symmetry in the ratings.)
• IQR: 1.0 (Tightly concentrated ratings between 5.5–6.5.)
• Range: 5.0–7.0 (A narrow overall range, with no outliers.)

Insights:

• The narrow spread and high median suggest that nearly all participants felt engaged and part of the interactions.
• High inclusion is a critical success factor in virtual agent design, as it reflects users feeling acknowledged and integrated into the conversational flow.

Implications:

• This aspect of the system is strong, and developers can build on this to ensure users continue to feel valued and included.

---

2. Conversation Realism

Summary: Users gave more moderate ratings to the realism of conversations, reflecting mixed opinions.
Statistical Breakdown:

• Median: 5.0 (Reflects that about half the participants rated this moderately.)
• Mean: ~5.2 (Slightly higher than the median, reflecting a positive skew.)
• IQR: 2.0 (Responses varied more significantly, between 4.0–6.0.)
• Range: 2.0–7.0 (Wide overall range, with the lowest ratings being 2.0.)

Insights:

• While the median indicates users were generally satisfied with conversation realism, the wider range shows disparity in user experience.
• Lower ratings (e.g., 2.0) highlight that some participants found the conversations artificial or lacking authenticity.

Implications:

• Developers should prioritize making conversations more dynamic and natural to bridge this gap in perception.
• AI improvements, such as nuanced emotional responses or better understanding of context, could elevate the sense of realism.

---

3. Agent Realism

Summary: Agent realism had the lowest scores overall, reflecting a key area for improvement.
Statistical Breakdown:

• Median: 4.0 (A low central score compared to other metrics.)
• Mean: ~4.3 (Close to the median, suggesting consistency in feedback.)
• IQR: 3.0 (Wide spread of ratings, from 3.0–6.0.)
• Range: 2.0–7.0 (Largest spread among all categories, with extreme high and low ratings.)

Insights:

• Users perceived the agents as less lifelike, with some finding them significantly unrealistic (lowest rating of 2.0).
• The ratings' variability indicates that while some users appreciated the agents’ realism, others were dissatisfied.

Implications:

• Enhancing agent realism could involve improving visual design, body language, and responsiveness to mimic human-like interactions.
• High variability also suggests that user expectations or prior experiences may influence their perception of realism. Tailored calibration based on user preferences could address this.

---

4. Comfort

Summary: Comfort was rated very positively, with only minor exceptions.
Statistical Breakdown:

• Median: 6.0 (Indicating most users felt comfortable overall.)
• Mean: ~6.1 (Slightly above the median, reflecting overall satisfaction.)
• IQR: 1.5 (Concentrated ratings between 5.5–7.0.)
• Range: 2.0–7.0 (Outlier of 2.0 indicates discomfort for one user.)

Insights:

• High comfort scores indicate users felt at ease in the virtual environment, with only one notable outlier experiencing significant discomfort.
• The positive sentiment here shows that the environment successfully supports user engagement and reduces friction.

Implications:

• Addressing outliers (e.g., participants who feel uncomfortable) can involve refining elements like interface usability or reducing cognitive load during interactions.
• Maintaining comfort is critical as it directly affects user satisfaction and willingness to engage further.

---

Holistic Findings and Recommendations

Positive Outcomes:

• Inclusion and Comfort were rated highly, indicating that users felt welcomed and at ease while interacting with virtual agents.
• These areas of strength suggest that the virtual environment is designed to foster a sense of engagement and ease of use.

Areas for Growth:

• Conversation Realism received moderate ratings, and the large variability suggests that some users find it less convincing. Improving conversational dynamics and personalization could enhance the experience.
• Agent Realism was the weakest category, showing the most substantial room for improvement. Upgrades to visuals, expressions, and interaction quality could elevate the perception of agents as "real people."

Outliers:

• The lower range ratings in Conversation Realism and Comfort indicate that specific users had negative experiences. Collecting qualitative feedback could help identify exact pain points.

Future Directions:

• Emphasize iterative testing: Address weaknesses in conversation and agent realism by iteratively testing new features and gathering user input.
• Focus on personalization: Adapt conversations and agent behaviors to better match individual user expectations.

Conclusion

Our pilot study shows that users felt a positive social presence when interacting with two embodied conversational agents in VR. Though focused on two agents, this study lays the groundwork for exploring multiple agents engaging users in VR. Our findings suggest that VR developers incorporating multiple agents can enhance users' sense of social presence.

References

Josyula, V., Mecheri-Senthil, S., Khawaja, A., Garcia, J. M., Bhardwaj, A., Pratap, A., & Kim, J. R. (2024). Virtual streamer with conversational and tactile interaction. 2024 IEEE Conference on Virtual Reality and 3D User Interfaces Abstracts and Workshops (VRW), 1072–1073. IEEE.

Qazi, M. H., & Qazi, M. P. (2023). Introducing VAIFU: A virtual agent for introducing and familiarizing users in VR. 2023 4th International Conference on Computing, Mathematics and Engineering Technologies (iCoMET), 1–6. IEEE.

Riches, S., Elghany, S., Garety, P., Rus-Calafell, M., & Valmaggia, L. (2019). Factors affecting sense of presence in a virtual reality social environment: A qualitative study. Cyberpsychology, Behavior and Social Networking, 22(4), 288–292. doi:10.1089/cyber.2018.0128
