Pointers and Arrays

• Concept area to understand what is a pointer and how they work with arrays.
• Read this post to understand more on pointers and variables with examples.
  • Below are C example programs from the above post.

Programs

Types and Memory

• Compile the code this way: gcc -Wall -Wextra -Werror -pedantic -std=gnu89 sizeof.c -o sizeof

Address of Variables

• Program shows you address of variables c and n.
• Compile the code this way: gcc address.c -o address

Pointer size and address

• Compile the code this way: gcc -Wall -Werror -pedantic -Wextra -std=gnu89 psize.c -o psize

Storing an address of a variable into a pointer

• Compile the code this way: gcc pn.c -o pn

Dereferencing (Hard term right here.)

• Part 1

  • Compile the code this way: gcc dereference_1.c -o dereference_1

• Part 2

  • Compile the code this way: gcc dereference_2.c -o dereference_2

Functions parameters are passed by value

• modif_my_param

  • Compile the code this way: gcc modif_main.c modif_my_param.c -o modif_param

• Assignment

  • Memory Address view
  • Compile the code this way: gcc modif_char_main.c modif_my_char_var.c -o modif_char

Arrays

• Compile the code this way: gcc array.c -o array

Arrays vs Pointer

• Array vs Pointer
  • Compile the code this way: gcc array_vs_pointer.c -o array_vs_pointer
• Array type Decay
  • Compile the code this way: gcc -o array_type_decay array_type_decay.c
• sizeof Usage in Array & Pointer
  • Compile the code this way: gcc -Wall -Werror -Wextra -pedantic -o sizeofarray sizeof_array.c
• Unary & Usage Array
  • Compile the code this way: gcc -o addressofarray address_of_array.c
• Size of array and address
  • Compile the code this way: gcc -o sizeof_array_address sizeof_array_address.c

Pointers Arithmetic

• Illustrates pointers arithmetic

  • Compile the code this way: gcc array.c -o array_pointers_arithmetic array_pointers_arithmetic.c

• pointers arithmetic

  • Compile the code this way: gcc pointers_arithmetic.c -o pointers_arithmetic

• Assignment

  • Compile the code this way: gcc solveme.c -o solveme
  • So before I proceeded to adding printf statements and filling up the memory layout excel file, I compiled the code and threw it in gdb, so below is the assembly code of the program without any printf function calls. (This is the best way to understand your code)
  Assembly Code

  <main>:       endbr64                                         ;\ standard function
  <main+4>:     push   rbp                                      ;
  <main+5>:     mov    rbp,rsp                                  ;/ prologue code
  <main+8>:     sub    rsp,0x30                                 ; allocates 48 byes on the stack
  <main+12>:    mov    rax,QWORD PTR fs:0x28                    ; moves the stack guard to $rax
  <main+21>:    mov    QWORD PTR [rbp-0x8],rax                  ; moves the stack guard from rax to the stack [rbp-0x8]
  <main+25>:    xor    eax,eax                                  ; clears out eax $rax
  <main+27>:    mov    DWORD PTR [rbp-0x20],0x62                ; moves integer 98 to the stack at location [rbp-0x20]
  <main+34>:    mov    DWORD PTR [rbp-0x1c],0xc6                ; moves integer 198 to the stak at location [rbp-0x1c]
  <main+41>:    mov    DWORD PTR [rbp-0x18],0x12a               ; moves integer 298 to the stack at location [rbp-0x18]
  <main+48>:    mov    DWORD PTR [rbp-0x14],0x18e               ; moves integer 398 to the stack at location rbp-0x14]
  <main+55>:    mov    DWORD PTR [rbp-0x10],0x1f2               ; moves integer 498 to the stack at location [rbp-0x10]
  <main+62>:    lea    rax,[rbp-0x20]                           ; load the address of integer 98 location and store it to $rax
  <main+66>:    add    rax,0x4                                  ; pointer arithmetic *(a + 1) adds 4bytes to address in $rax
  <main+70>:    mov    QWORD PTR [rbp-0x30],rax                 ; moves the result from $rax to [rbp-0x30] and stored as a 64bit address
  <main+74>:    mov    rax,QWORD PTR [rbp-0x30]                 ; moves the address that contains integer 198 from [rbp-0x30] to $rax
  <main+78>:    mov    DWORD PTR [rax],0x62                     ; (dereferencing) moves integer 98 to the address in $rax
  <main+84>:    lea    rax,[rbp-0x20]                           ; load the address with the new integer value 98 to $rax
  <main+88>:    add    rax,0xc                                  ; pointer arithmetic *(a + 3) adds 12 bytes to address in $rax
  <main+92>:    mov    QWORD PTR [rbp-0x28],rax                 ; moves the result from $rax to [rbp-0x28] and stores as a 64bit address
  <main+96>:    mov    rax,QWORD PTR [rbp-0x30]                 ; moves the 64bit address in [rbp-0x30] that contains integer 98 to $rax
  <main+100>:   mov    eax,DWORD PTR [rax]                      ; moves value 98 to eax
  <main+102>:   lea    edx,[rax+0x539]                          ; (dereferencing) move value in $rax + 1337 == [rax+0x539] to $edx == 1435
  <main+108>:   mov    rax,QWORD PTR [rbp-0x28]                 ; moves address in [rbp-0x28] to $rax
  <main+112>:   mov    DWORD PTR [rax],edx                      ; moves value 1435 in $edx to address from [rbp-0x28] that's in $rax
  <main+114>:   mov    eax,0x0                                  ; clears $eax
  <main+119>:   mov    rdx,QWORD PTR [rbp-0x8]                  ; moves stack guard to $rdx from the stack
  <main+123>:   sub    rdx,QWORD PTR fs:0x28                    ; checks if stack guard is the same
  <main+132>:   je     0x5555555551d4 <main+139>                ; if its the same then we can leave the program
  <main+134>:   call   0x555555555050 <__stack_chk_fail@plt>    ; if not a function call is made to stack_chk_fail
  <main+139>:   leave                                           ; leaves the program
  <main+140>:   ret                                             ; return value

  • Memory Address view

• Compile the code this way: gcc -o solveme solveme.c

Strings

• string array using pointer arithmetic
  • Compile the code this way: gcc string_array.c -o string_array
• string array the proper way
  • Compile the code this way: gcc array_string.c -o array_string
